Case-Study Case-Study, RF, DSP, Signal Processing Case-Study RF DDC NCO CIC CORDIC DSP

Digital Down-Conversion: bringing a carrier to baseband without analog mixers

A large family of measurements does not deliver its information at DC. It arrives riding on a carrier: the free induction decay of an NMR or EPR experiment, the response of a resonant sensor driven at its resonance, the return of a swept optical or acoustic interrogator, the output of an RF front end.

Read More +

Case-Study Case-Study, RF, DSP, Signal Processing Case-Study Lock-In RF NCO CORDIC Modulation Low Noise

A lock-in amplifier that lives entirely in the FPGA

A lock-in amplifier is the standard answer to one specific problem: you have a signal you can modulate, and it is far smaller than the noise sitting on top of it.

Read More +

Case-Study Case-Study, RF, DSP, Signal Processing Case-Study Goertzel Impedance Spectroscopy RF DSP Resources

Watching a handful of frequencies without paying for an FFT

Electrochemical impedance spectroscopy measures a cell at a dozen or so discrete frequencies. A resonant sensor is interrogated at its resonance and at two points on the skirt.

Read More +

Case-Study Case-Study, DSP, Signal Processing, Trigger Case-Study Matched Filter FFT Fast Convolution Trigger SNR

A matched filter at full sampling rate, using fast convolution

If you know the shape of the pulse you are looking for, the filter that maximises the signal-to-noise ratio at the moment of detection is the matched filter: correlate the incoming stream with a time-reversed copy of that shape.

Read More +

Case-Study Case-Study, DSP, Signal Processing, Monitoring Case-Study FFT Windowing Spectrum Microphonics Monitoring

Continuous spectral monitoring: finding a line that should not be there

Some of the most useful measurements an instrument makes are not of the thing it was built to measure. A cryostat develops microphonics from a pump that was fine last month.

Read More +

Case-Study Case-Study, DSP, Signal Processing, Detector Case-Study Averaging Pump-Probe LIDAR ToF Template SNR

Coherent averaging for repetitive signals, with pile-up thrown away

Whenever a measurement can be repeated on demand, averaging is the cheapest signal-to-noise ratio available. Pump-probe spectroscopy, time-of-flight measurement, LIDAR return profiling, ultrasound, laser-induced breakdown, and the routine business of extracting a detector’s pulse shape all share the same structure: fire something, capture the response, do it again.

Read More +

Case-Study Case-Study, Signal Generation, Testing, DSP Case-Study Noise Pink Noise PRNG Testing Signal Generation Dither

Noise you can specify: choosing the right disturbance for a test

“Add some noise and see if it still works” is one of the most common things said about a signal-processing design, and one of the least precise.

Read More +

Case-Study Case-Study, Multi Channels, Design Flow, DSP Case-Study TM Time Multiplexing X2730 500 MS/S Concepts

Time multiplexing: what a TM signal is and what a lane means

Every block in the Sci-Compiler library now exists in two versions, and the second one is marked TM. Understanding what that means takes about ten minutes and saves a great deal of confusion, because TM is one mechanism that solves two quite different problems, and the mechanism cannot tell you which of the two you are using it for.

Read More +
